1050 1060 1100 1200 3003 cost price insulation aluminum coil

Quick Details

1. cost price insulation aluminum coil

2.  Free samples  can be provided for you to test.

3. Size:

    thickness: 0.2--10mm

    width: 90--2500mm

4. alloy: 1050 1060 1070 1100 3003 5052

5. The specification can be produced by your requirements.

Product Description

Aluminum Coil Discription

1.	Item	insulation aluminum coil
2.	Standard	ASTM B221M, GB/T 3191, JIS H4040, etc.
3.	alloy	1050 1200 1060, 1100, 1200, 3003, 3004
4.	Temper	O H12 H14 H16 H18 H19 H22 H24 H26 H28
5.	Specifications	thickness	0.2--10mm
		Width	90--2200mm
		Coil ID	505mm 508mm 605mm 405mm 610mm 300mm
6.	Surface	Mill finish, polished, mirror finish anodizing, brushing, sand blasting, powder  coating,  etc.
7.	Price Term	Ex-work, FOB, CIF , CFR, etc.
8.	Payment Term	T/T, L/C
9.	Delivery Time	According to order’s quantity.
10.	Package	Export standard package: bundled wooden box, suit for all kinds of transport,  or be  required.
11.	Application	1) Kitchenware, food and chemical products processing and storage devices; 2) Aircraft fuel tanks, oil pipe, rivets, wire; 3) Cans cover, car body panels, steering plates, stiffeners, brackets and other  components; 4) Manufacturing trucks, tower building, ship, train, furniture, machinery parts,  precision machining with the tubes, rods, shaped, sheet metal.
12.	Contact	If you have any question, please feel free contact Lula.



Chemistry  Composition & Mechanical Properties

Chemistry  Composition   of  aluminum coil
alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Al
1050	0.250	0.400	0.050	0.050	0.050	-	0.050	0.030	99.5
1060	0.250	0.350	0.050	0.030	0.030.-	-	0.050	0.030	99.6
1070	0.200	0.250	0.040	0.030	0.030	-	0.040	0.030	99.7
1100	Si+Fe:0.95		0.05-0.2	0.050	-	-	0.100	-	99.0
1200	Si+Fe:1.00		0.050	0.050	-	-	0.100	0.100	99.0
1145	Si+Fe:0.55		0.050	0.050	0.050	-	0.050	-	99.45
3003	0.600	0.700	0.05-0.20	1.0-1.5	-	-	0.100	-	remains
3004	0.300	0.700	0.250	1.0-1.5	0.8-1.3	-	0.250	-	remains
